常见数控机床报警信息中英文对照,值得收藏!

2020-07-07 09:33:40

T WORD ERROR (T 码错误)

LOW OIL LEVEL (油位低)

SPINPLE FAULT (主轴故障)

SPINDLE ALARM (主轴报警)

EXTERNAL EMG STOP (急停按钮被按下)

AC NOT READY (交流盘未准备好)

SPINPLE LUBE FAULT (主轴润滑故障)

T CODE ERROR (T代码出错,非法T代码)

M CODE ERROR (M代码出错,非法M代码)

SERVO NOT READY (伺服未准备好)

NC NOT READY(NC没准备好)

TURRET FAULT (转塔故障)

TURRET LIMIT (转塔限位)

DC 24V OPEN (直流24断开)

+24V NOT READY(+24V没准备好)

GRAR DRIFT (档位漂移)

PLEASE AXIS RETURN HOME(轴未回零)

PLEASE DRUM RETURN HOME(刀库未回零)

AIRPRESSFAILURE(气压故障)

UNCL TOOL FALL(松刀失败)

AIR PRESSURE DROP (压缩空气压力过低)

CLAMP TOOL FALL(夹刀失败)

DRUM NOT PARKED(刀库未在原值)

X ZERO POINT NOT REACHED (X 轴未回零)

Y ZERO POINT NOT REACHED (Y 轴未回零)

Z ZERO POINT NOT REACHED (Z 轴未回零)

4TH ZERO POINT NOT REACHED (第4轴未回零)

X AXIS OVERTRAVL(X轴超限)

Y AXIS OVERTRAVL (Y轴超限)

Z AXIS OVERTRAVL (Z轴超限)

苏州数控机床公司

COUNTER SWITCH REEOR (计数开关故障)

MASTERT RANSFER OVER TEMP (主变压器过热)

Z AXIS NOT AT FIRST REF POSITION (Z轴未在一参考点)

SPINDLE ORIENTATION FALLURE (主轴定向失败)

TOOL DESENT OR TOOL DATA REEOR (刀具数据错误)

PLEASE UNLOAD THE TOOL ON SPRINELK (请卸下主轴上的刀)

PLEASE LOAD TOOL ON APINDLE (请装上主轴上的刀)

A AXIS UNCLAMP FAIL (A 轴松开失败)

A AXIS CLAMP FAIL (A 轴夹紧失败)

DRUM OUT TO APRONDLEIS FALL (刀库摆向换刀位失败)

MG SWING OVERLOAD(刀库摆动过载)

DRUM BACK PARK IS FALL (刀库摆回原始位失败)

TURRENT MOTOR1 OVERLOAD (刀库移动电机过载)

COOLANT MOTOR OVERLOAD (冷却泵过载)

DRUM ATC FAULT (自动换刀失败)

TOOLS UNLOCKED (刀具未锁紧)

BATTERY ALARM (电池报警)

DRUM POSITION SWITCH ERROR (刀库位置检测开关故障)

DRUM NOW NOT AT PARK (刀库未在原始位置)

IT DANGOU TO MOVE DRUM (刀库禁动)

POT UO FAILOR POT NOT AT UP POSITION (刀套未在水平位)

POT DOWN FAIL (刀套翻下动作失败)

IT IS DANGOUR TO MOVE ARM (机械手禁动)

THE SPINDLE STATU IS ERROR (主轴状态错误)

ARM MOTOR OR ARM SWITCH FALL (机械手或机械手开关故障)

CENTRE LUBRICATION FALL (中心润滑故障)

THE WORK NOT CLAMPED (工件未夹紧)

AUTO TOOL CHANGE FAULT (自动换刀失败)

TOOL DATA OUT OF RANGE (指令刀具号超出范围)

THE ORDER TOOL NOW IN SPINDLE (目标刀具在主轴上)

THE THREE SPINDLE SWITCH FAULT (主轴上的接近开关)

THE CENTRE COOLANT IS LOWER (刀具内冷泵液位过低)

DRUM RETURN 1# POSITION FAULT (刀库自动回零失败)

SPINDLE OVERLOAD (主轴过载)

TURRENT MOTOR OVERLOAD (刀盘转动电机过载)

CHIP CONVEYER OVERLOAD (拉屑器过载)

HARD LIMIT OR SERVO ALARM (硬限位或伺服报警)

NO LUB OIL (无润滑油)

INDEX HEAD UNLOCKED (分度头未锁紧)

MT NOT READY(机床没准备好)

MG OVERLOAD (刀库过载)

LUB EMPTY(润滑无油)

AIR PRESSURE(气压不足)

COOLANT NOT READY(冷却没准备好)

LUBE EMPTY(油雾油位低,润滑油位低)

LUB PRESSURE LOW(润滑压力低)

CONVEY VERLOAD(排屑过载)

LUB OVERLOAD(润滑过载)

LUBE PRESSURE LOW(油雾压力低)

SERIAL SPINDLE ALARM (串行主轴报警)

NC BATTERY LOW ALARM(NC电池低报警)

MAGAZINE MOVE LIMIT SWITCH ERROR

SPINDLE TOOL UNLAMP POSITION LIMIT SWITCH ERROR

MAGAZINE NOT IN POSITION OR SENSOR ERROR

AIR PRESSURE LOW ALARM(气压低报警)

MOTOR OVERLOAD(电机过载)

T CODE > MAGAZINE TOOLS

T CODE < 1 ERROR

5TH AXIS HARDWARE OVERTRAVER LIMIT ERROR

DOOR IS OPENED(开门)

LUB PRESSURE SWITCH ERROR(油压开关错误)

SPINDLE OIL COOLANT UNIT ERROR

SPINDLE LOAD ABNORMAL(主轴负荷异常)

TRANSDUCER ALARM(传感器报警)

BED-HEAD LUBRICATE OFF(床头润滑关闭)

EMG OFF

HYDRAULIC CHUCK PRESS LOW(液压夹头压力低)

HYDRAULIC TAIL PRESS LOW(液压尾座压力低)

LUB 0IL LOW(油压低)

TURRET CODE ERROR(转塔码错误)

TURRET RUN OVERTIME(转塔运行超时)

MANUAL HANDLE INTERRUPT

TRY TO RUN SPINDLE WHILE CHUCK NOT LOCK

TRY TO RUN SPINDLE WHILE TAIL NOT LOCK

SPINDLE NEUTRAL GEAR

MAGAZINE ADJUST

HYDRAULIC NOT RUN

SAFETY DOOR BE OPENED

SAFETY DOOR NOT CLOSE

NOT ALL AXIS HAVE GONE BACK REF

IN ADJUST,IGNORE GOING BACK REF

AFTER EXCHANGE TOOL,CYCLE START

ATC MOTOR QF16 OFF

X AXIS IS LOCKED(X 轴被锁定)

Y AXIS IS LOCKED(Y 轴被锁定)

Z AXIS IS LOCKED(Z 轴被锁定)

A AXIS IS LOCKED(A 轴被锁定)

SPINDLE MOTOR FAN QF26 OFF(主轴电机风扇QF26关闭)

SPINDLE ORIENTATION INCOMPLETE(主轴定位不完全)

M FUNCTION NOT COMPLETE(M 功能无法完成)

SPINDLE NOT IN GEAR POSITION(齿轮不在主轴位置)

SPINDLE NOT CHANGED TO LOW GEAR(主轴没有变为低档)

SPINDLE NOT CHANGED TO HIGH GRAR(主轴没有变为高档)

MAG NOT BACKWARD

SPINDLE TOOL NOT CLAMP

SPINDLE TOOL NOT UNCLAMP

MAG NOT IN POSITION

MAG DOES NOT ROTATE

MAG DOES NOT STOP RUNNING

A AXIS HAVE NOT CLAMPED

A AXIS HAVE NOT UNCLAMPED

SET D499=1,"MAG.JOG" SWITCH ON

HYDRAULIC MOTOR QF7 OFF( 液压马达QF7关闭 )

HYDRAULIC TEMPRETURE HIGH( 液压使用温度高 )

HYDRAULIC FILTER BLOCKED(液压过滤器阻止)

HYDRAULIC OIL LEVEL LOW( 液压油位低 )

HYDRAULIC FAN QF8 OFF(液压风扇QF8关闭)

HELIX CONYER QF9 OR QF10 OFF

CHAIN CONYER QF11 OFF

COOLANT MOTOR QF12 OFF(冷却液电机QF12关闭)

COOLNT LEVEL LOW,CYCLE STOP AFTER 20 MINUTES

INNER COOLANT BLOCK(内冷却堵塞)

SPINDLE COOLANT MOTOR QF14 OFF(主轴冷却液电机QF14关闭)

INNER COOLANT QF13 OFF(内冷却液QF13关闭)

MAG MOTOR QF15 OFF

CABINET COOLANT EQUIP QF20 OFF

OIL GATHER QF24 OFF

AIR PRESSURE LOW(低气压)

SPINDLE COOLANT MOTOR FAULT(主轴冷却液电机故障)

LUB.OIL IS LOW(润滑油低)

DOOR OPEN(门打开)

FRONT DOOR(R) OPEN(前门打开)

LEFT DOOR OPEN(左门打开)

LUBRICATION OIL QF23 OFF(润滑油QF23关闭)

LUBRICATION PRESS LOW(润滑油位低)

IN ADJUST,MAG CAN'T EXCHANGE T(在调整,刀库不能交换T)

NOT ALL DOOR CLOSED(门没有全部关闭)

IN M06,MAG NOT READY(在M06,刀库未准备好)

MAGAZINE NOT READY(刀库未准备好)

POCKET NOT HORIZANTAL

IN M06,Z NOT BACK TO 2ND REF

IN M06,Z AXIS NOT IN PSW1

ATC NOT IN ZERO POSITION

SPINDLE ORIENTATION UNCOMPLETE

POCKET NOT HOR./MAG NOT BCKWRD

POCKET NOT VER./MAG NOT FORWRD

UNCLAMP TOOL HAS NOT COMPLETED

CLAMP TOOL HAS NOT COMPLETED

AIM TOOL NO. IS WRONG

MAG NOT BACKWARD

AFTER RETRACT,SET R.T.BACK OFF

Z NOT IN PSW2,FORBID ATC RUNNING

D499 EQUAL 1

MAG.JOG SOFT SWITCH IS ON

Z NOT IN PSW2,FORBID MAG FORWARD

CHEKE SPINDLE MODULE ALARM

OIL WATER SEPARATOR QF24 OFF

SET THE SOFT SWITCH MAG.JOG OFF

SET D499 TO 0 设定D499为0

K PARAM ABOUT MAG SET IS WRONG 关于MAG的K参数设定错误

MECHANICAL BRAKE NOT RELEASED机床抱闸没有松开

MECHANICAL BRAKE IS WRONG 机床抱闸错误

PLEASE ADD LUB.OIL 请加润滑油

PROBE BATTERY VOLTAGE IS LOW 探头电池电压低

PROBE IS ERR 探头错误

PARAMETER WRITE ENABLE(参数写使能)

PMC EDIT ENABLE(PMC编辑使能)

CHECK LUB ROUTIN

SPINDLE GEAR SIGNAL MISS 主轴档位信号消失

T_CLAMPED_SIGNAL MISS T夹紧信号消失

SP OVERRIDE SWITCH DISCONNECTION 主轴倍率开关断路

FEED OVERRIDE SWITCH DISCONNECTION 进给倍率开关断路

THE TOTAL NUMBER OF POCKETS SET ERR

CHANGE T STOPED BECAUSE NO AIR 因为缺少压空交换停止

THE COOLANT WATER TOO LOW,ADD COOLANT WATER AT ONCE 冷却水少立即加水

COOLANT LEVEL LOW,ADD COOLANT WATER 冷却水液位低

PLEASE REPLACE CNC BATTERY QUICKLY 请立即更换CNC电池

SIEMENS常用缩略语

A Output 输出

ASCII American Standard Code for Information Interchange 美国信息交换标准代码

AV Preparation for work 运行准备

BA Operating mode 运行方式

BAG Operating mode groups 运行方式组

BB Ready for operation 准备好运行

BCD Binary Coded Decimals 二-十进制

BHG Hand-held terminal 手提终端

BOF User interface 用户接口

CNC Computerized Numerical Control 计算机化数字控制

CP Communication Processor 通迅处理器

CPU Central Processing Unit 计算机中央处理装置

CR Carriage Return 托架折回

CSB Central Service Board(PLC module) 中央维护板,PLC 模块

CTS Clear To Send 发送使能

DAU Digital-Analog Converter 数模转换器

DB Data Block 数据块

DIN German Industrial Standards 德国工业标准

DIO Data Input/Output 数据输入/输出

DRF Differential Resolver Function 差分功能

DRY Dry Run 空运行

DSB Decoding Single Block 译码单段

DSR Data Send Ready 备用输入

DW Data Word 数据字

E Input 输入

EIA-Code Special tape code,number of holes per characters always odd 特殊纸带码,每个字符的孔数为奇数

EPROM Programm memory with fixed program 有固定程序的程序存储器

E/R Controlled Supply and Energy Recovery Module 可控电源和能量恢复模块

ETC ETC key:Extension of the softkey bar in the same menu

ETC 键:同级菜单扩展键

FDB Product designation database 产品指定数据库

FIFO First in First Out 先进先出

FRA Frame module 帧频模块

FRAME Coordinate conversion with the components zero

offset,rotation,scaling,

mirror-imaging 坐标换算,具有零点偏置,坐标旋转,标度功能和镜向功能

FRK Cutter radius compensation 铣刀半径补偿

FST Feed Stop 停止进给

GUD Global User Data 全体用户数据

HMS High-Resolution Measuring System 高分辨率测量系统

HSA Main Spindle Drive 主轴驱动

HW Hardware 硬件

IM Interface Module 接口模块

IM-S/R Interface Module(S=send/R=receive) 接口模块,S=发送/R=接收

INC Increment 步进增量

ISO-Code Special tape code,number of holes per character always even

特殊纸带码,每个字符的孔数为偶数

K1...k4 Channel 1 to Channel 4 通道1 到通道4

KOP Ladder Diagram 梯形图

KV Loop-Gain Factor 增益系数

KUE Transformation Ratio 传动比

LCD Liquid Crystal Display 液晶显示

LED Light Emitting Diode 发光二极管显示

LUD Local User Data 局部用户数据

MB Megabyte 兆字节

MD Machine Data 机床数据

MK Measuring Circuit 测量回路

MDA Manual Data Automatic 手动输入,自动执行

MLFB Machine-readable product designation 机器可识别的产品代号

MMC Man Machine Communication:User interface of the numerical control

system for operation,programming and simulation 人机通讯:系统操作界面,用操作,编程和模拟

MPF Main Program File:NC part program(main program)

NC 零件程序,主程序

MPI Multi Point Interface 多点通讯接口

MSTT Machine control panel 机床控制面板

NC Numerical Control 数字控制

NCK Numerical Control Kernel(numerical krnel with block preparation,

traversing range etc.) 数字控制核心:具有程序段预处理,运行范围等等

NCU Numerical Control Unit 数控单元

NURBS Non Uniform Rational B Spline 非均值有理B样条

NV Zero Offset 零点偏置

OEM Original Equipment Manufacturer 原设备制造商

OP Operator Panel 操作面板

OPI Operator Panel Interface 操作面板接口

PC Personal Comprter 个人计算机

PCMCIA Personal Computer Menory Card International Association 接口协议

PG Programming Device 编程器

PLC Programmable Logic Control 可编程逻辑控制器

PRT Program Test 程序测试

RAM Random Access Memory 随机存取存储器

RISC Reduced Instruction Set Computer 处理器,具有指令组小、通过能力强

ROV Rapid Override 快速修调

RPA R Parameters Active(NCK memoty area for R parameter numbers)

R 参数有效,NCK 中用于R 参数号的存储器区

RTS Request To Send(control signal from serial data interfaces)

发送请求:来自串行接口的控制信号

SBL Single Block 单段

SBL2 Single Block Decoding 译码单段

SEA Setting Data Active(memory area for setting data in NCK)

设定数据有效:用于NCK 中设定数据的存储区

SD Setting Data 设定数据

SKP Skip Block 程序段跳跃

SM Signal Module 信号模块

SPF Sub Program File 子程序文件

SPS Programmable Logic Controller 可编程逻辑控制器

SRK Cutter Radius Compensation 刀尖半径补偿

SSFK Leadscrew Error Compensation 丝杠螺距误差补偿

SSI Serial Synchronous Interface 串行同步接口

SW Software 软件

TEA Testing Data Active(with reference to the machine data) 测试数据有效:与机床数据有关

TO Tool Offset 刀具补偿

TOA Tool Offset Active(memory area for tool offset) 刀具补偿有效,用于刀补的存储区

TRANSMIT Transform Milling into Turning(coordinate conversion on

turning machines for milling)

铣床转换为车床:车床坐标换算用于铣削加工

VSA Feed drive(spindle) 主轴进给驱动

V Bit type PLC variable PLC变量类型:位

VB Byte type PLC variable

PLC变量类型:字节

WKZ Tool 刀具

WZ Tool 刀具

WZK Tool offset 刀具补偿

ZOA Zero Offset Active(memory area for zero offsets)

零点偏置有效:零点偏置存储区
